Product Description

MG380Hybrid MG380Hybrid-12100 MG380Hybrid-25100 Laser Wattage RF driven metal laser tube: 12W RF driven metal laser tube: 25W DC driven glass laser tube: 100W DC driven glass laser tube: 100W Laser Source Sealed CO2 Laser Laser Cooling RF driven laser tube: Air Cooled; DC driven laser tube: Water Cooled Working Area 38 x 24 in. ( 960 x 610 mm ) Max. Part Size (W x L x H) All doors closed 41 x 25 x 6.5 in. ( 1041 x 635 x 165 mm ) All doors open 41 x ∞ x 6.5 in. ( 1041 x ∞ x 165 mm ) Table Size 42.7 x 29.5 in. ( 1085 x 750 mm ) Dimensions (W x L x H) 68.9 x 48.9 x 40 in. (1750 x 1242 x 1017 mm) Driving Motor Closed-loop DC Servo Control Maximum Motor Speed 40 IPS Speed Control Adjustable from 0.1~100% ( Up to 16 color-linked speed settings per job ) Power Control Adjustable from 0~100% ( Up to 16 color-linked power settings per job ) Engraving Capability 256-level gray scale image processing capability Distance Accuracy 0.254 mm or 0.1% of move, whichever is greater Resolution (DPI) Available 125, 250, 300, 380, 500, 600, 760, 1000 Z-Axis Movement Automatic Focus Lens Standard 2.0″, optional 1.5″, 3″ Computer Interface 10 Base-T Ethernet, Full speed 2.0 USB Memory Buffer 32MB standard Safety Class I Laser Product Compliant with EN60825 Class II Laser Product Compliant with CDRH Facility Requirements Operation Voltage 200-240VAC, 50/60Hz auto switching, Max. 8A Water Chiller External water chiller required Fume Extraction System External exhaust system with minimum flow rate 640m3/h required to connect to 8-inch or 4-inch connection port on machine. *Speed is not equal to throughput. See dealer or visit www.GCCworld.com for more details. Specifications are subject to change without prior notice. ♦TW Patent I430864 ♦US Patent 8,748,775 B2 *The flow rate is determined by a default fume extraction system; the flow rate may vary due to a di fferent fume extraction system.​
